TS-410E-8G 4BAY 2.5in SATA J6412 QC 8GB ONBOARD 2X 2.5in GBE

Introduction

The TS-410E professional 2.5GbE NAS is designed to operate in noise-sensitive environments. With a fanless design and rock-solid chassis, the TS-410E can be placed upright to save desktop space. SSD caching can also be configured for high-speed I/O to accelerate and excel in demanding applications.

2.5GbE connectivity
Up to 5Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE ports.

4K HDMI output
Supports 4K playback and real-time transcoding for utmost visual experience!

Optimized SSD performance and lifespan
Install SATA 6Gb/s SSDs and activate SSD caching for increased IOPS performance.

Ultra-silent
The fanless, low vibration design keeps the TS-410E cool and quiet while also preventing dust buildup.

Multimedia streaming
Centrally store, access, and stream photos, music, and videos.

Data backup and recovery
A reliable backup center for your PC/Macs, virtual machines, containers, cloud data, and SaaS data.

Storage

Supported storage drive interfaces

Serial ATA III

Storage drive sizes supported

2.5"

Storage drives installed

N

Number of storage drives supported

4

Installed storage drive type

N

Supported storage drive types

HDD & SSD

RAID support

Yes

RAID levels

0, 1, 5, 6, 10, JBOD

Hot-swap drive bays

Yes

Online RAID migration

Yes

Online RAID expansion

Yes

RAID rebuild

Yes

Supported file systems

FAT32, HFS+, exFAT, ext3, ext4

Auto-rebuild

Yes

Bad block scan

Yes

Total installed storage capacity

0 TB

Processor

Processor manufacturer

Intel

Processor family

Intel® Celeron®

Processor frequency

2.6 GHz

Processor cores

4

Processor threads

4

Processor model

J6412

Memory

Internal memory

8 GB

Maximum RAM supported

8 GB

Flash memory

4000 MB

Network

Ethernet LAN

Y

Wake-on-LAN ready

Y

Jumbo frames support

Yes

Ports & interfaces

USB port

Y

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

4

HDMI ports quantity

1

HDMI version

1.4b

Ethernet LAN (RJ-45) ports

2

Design

Chassis type

Tower

Cooling type

Passive

Product colour

Black

LED indicators

LAN, Power, SSD, Status

Cable lock slot

Yes

Cable lock slot type

Kensington

Performance

Type

NAS

Buzzer

Y

Reset button

Y

On/off switch

Y

Device class

Small & Medium Business

Backup function

Yes

Multilingual support

Yes

System log

Yes

Disk scan

Yes

S.M.A.R.T. support

Yes

Backup button

Yes

Software

Operating system installed

QNAP QTS

Operating system version

5.0.1

Windows operating systems supported

Yes

Linux operating systems supported

Yes

Mac operating systems supported

Yes

Power

Power supply location

External

Power supply unit (PSU) capacity

90 W

AC input voltage

100 - 240 V

Power consumption (typical)

22.694 W

Power consumption (sleep)

13.494 W

Weight & dimensions

Width

180 mm

Depth

254 mm

Height

65 mm

Weight

2.54 kg

Package weight

3.73 kg

Package width

325 mm

Package depth

180 mm

Package height

271 mm

Operational conditions

Operating temperature (T-T)

-40 - 70 °C

Operating relative humidity (H-H)

5 - 95%

Storage temperature (T-T)

-45 - 85 °C

Storage relative humidity (H-H)

5 - 95%

Packaging content

Package type

Box

Other features

Warranty period

3 year(s)
