Core i7 Processor I7-6700te 2.4 GHz 8MB Cache Oem (cm8066201937801)

Introduction

The 6th generation Intel® Core™ i7 processors deliver a new class of computing with a host of new features to power the next generation of laptops and 2 in 1 PCs. Expect lighting fast speeds and peak performance through even the toughest of tasks and games. The built-in revolutionary Intel® Hyper-Threading Technology allows each processor core to work on two tasks at the same time for smoother multitasking while Intel® Iris™ graphics delivers stunning 3D visuals and faster, more advanced video and photo editing. Game the way you want and push the boundaries with overclocking for your most demanding gaming needs. The ultimate in peak performance.

Ready. Wake. Create.
From zero to power in a flash, the 6th generation Intel® Core™ processor wakes quicker than ever and lets you switch in and out of apps more seamlessly than ever.

Stunning Visual Experiences
With 6th generation Intel® Core™ processor Ultra HD graphics, your screen comes to life. Watch in a whole new way with 4k screens. Wireless displays let you create and game anywhere.

Security You Can Trust
Worry-free and hassle-free security is yours. With facial recognition and True Key™ technology, getting you logged in and protected has never been easier or more secure.

Processor

Processor manufacturer

Intel

Processor generation

6th gen Intel® Core™ i7

Processor model

i7-6700TE

Processor base frequency

2.4 GHz

Processor family

Intel® Core™ i7

Processor cores

4

Processor socket

LGA 1151 (Socket H4)

Component for

PC

Processor lithography

14 nm

Processor series

Intel Core i7-6700 Desktop series

Processor threads

8

System bus rate

8 GT/s

Processor operating modes

64-bit

Processor boost frequency

3.4 GHz

Processor cache

8 MB

Processor cache type

Smart Cache

Thermal Design Power (TDP)

35 W

Box

N

Cooler included

N

Generation

6th Generation

Compatible chipsets

Intel® B150, Intel® H110, Intel® H170, Intel Q150, Intel® Q170, Intel® Z170

Stepping

R0

Bus type

DMI3

Memory bandwidth supported by processor (max)

34.1 GB/s

Processor codename

Skylake

Processor code

SR2LP

Processor ARK ID

88201

Memory

Maximum internal memory supported by processor

64 GB

Memory types supported by processor

DDR4-SDRAM,DDR3L-SDRAM

Memory clock speeds supported by processor

1333,1600,1866,2133 MHz

Memory channels

Dual-channel

Memory voltage supported by processor

1.35 V

ECC

N

Graphics

On-board graphics card

Y

On-board graphics card model

Intel® HD Graphics 530

Maximum on-board graphics card memory

64 GB

On-board graphics card outputs supported

Embedded DisplayPort (eDP),DisplayPort,HDMI,DVI

On-board graphics card base frequency

350 MHz

On-board graphics card dynamic frequency (max)

1000 MHz

Number of displays supported (on-board graphics)

3

On-board graphics card 4K support

Y

On-board graphics card DirectX version

12.0

On-board graphics card OpenGL version

4.5

On-board graphics card maximum resolution (DisplayPort)

4096 x 2304 pixels

On-board graphics card maximum resolution (eDP - Integrated Flat Panel)

4096 x 2304 pixels

On-board graphics card maximum resolution (HDMI)

4096 x 2304 pixels

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

60 Hz

On-board graphics card refresh rate at maximum resolution (HDMI)

24 Hz

On-board graphics card ID

0x1912

Features

Execute Disable Bit

Y

Idle States

Y

Thermal Monitoring Technologies

Y

Market segment

Embedded

Maximum number of PCI Express lanes

16

PCI Express slots version

3.0

PCI Express configurations

1x16,2x8,1x8+2x4

Supported instruction sets

SSE4.1,SSE4.2,AVX 2.0

Scalability

1S

CPU configuration (max)

1

Embedded options available

Y

Graphics & IMC lithography

14 nm

Thermal solution specification

PCG 2015A

PCI Express CEM revision

3.0

Harmonized System (HS) code

8542310001

Export Control Classification Number (ECCN)

5A992C

Commodity Classification Automated Tracking System (CCATS)

G077159

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology)

Y

Intel® Identity Protection Technology (Intel® IPT)

Y

Intel® Turbo Boost Technology

2.0

Intel® Quick Sync Video Technology

Y

Intel® InTru™ 3D Technology

Y

Intel® Wireless Display (Intel® WiDi)

Y

Intel® Clear Video HD Technology (Intel® CVT HD)

Y

Intel® Insider™

Y

Intel® AES New Instructions (Intel® AES-NI)

Y

Enhanced Intel SpeedStep Technology

Y

Intel Trusted Execution Technology

Y

Intel® Memory Protection Extensions (Intel® MPX)

Y

Intel® Turbo Boost Technology 2.0 frequency

3.4 GHz

Intel® Transactional Synchronization Extensions

Y

Intel Enhanced Halt State

Y

Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)

Y

Intel VT-x with Extended Page Tables (EPT)

Y

Intel® Secure Key

Y

Intel TSX-NI

Y

Intel Stable Image Platform Program (SIPP)

Y

Intel® OS Guard

Y

Intel® Small Business Advantage (Intel® SBA)

Y

Intel Clear Video Technology

Y

Intel Software Guard Extensions (Intel SGX)

Y

Intel 64

Y

Intel Identity Protection Technology version

1.00

Intel Secure Key Technology version

1.00

Intel Small Business Advantage (SBA) version

1.00

Intel Stable Image Platform Program (SIPP) version

1.00

Intel Virtualization Technology (VT-x)

Y

Intel Virtualization Technology for Directed I/O (VT-d)

Y

Intel TSX-NI version

1.00

Conflict-Free processor

Y

Intel® Boot Guard

Y

Intel® vPro™ Platform Eligibility

Y

Technical details

Bus bandwidth

8

Bus type units

GT/s

Launch date

Q4'15

Maximum resolution & refresh rate (DisplayPort)

4096x2304@60Hz

Maximum resolution & refresh rate (HDMI)

4096x2304@24Hz

Maximum resolution & refresh rate (Integrated Flat Panel)

4096x2304@60Hz

Maximum resolution & refresh rate (VGA)

N/A

Processor cache

8192 KB

Product type

Processor

Status

Launched

Maximum memory

64 GB

Processor brand name

Intel Core i7 Intel Core i7 Processor

Supported memory types

DDR4-SDRAM,DDR3L-SDRAM

Last change

63903513

Maximum resolution (WiDi)

1080p

Product family

6th Generation Intel Core i7 Processors

Bus speed

8 GT/s

Maximum graphics card memory

64 GB

Processor ID

0x1912

Weight & dimensions

Processor package size

37.5 x 37.5 mm

Other features

Maximum internal memory

64 GB

Maximum internal memory

65536 MB

Graphics output

eDP/DP/HDMI/DVI

Video decoding

Y
