10g Multimode 1310nm Sfp+/ Ddm/ Duplex Lc Connector/ 2km

Introduction

Description

The SilverNet 10Gbps Singlemode and Multimode SFP+ modules are ideal for use on 10G high capacity networks. They make extending Ethernet over distance easy using the Fibre ports on switches to daisy chain together. The SilverNet SFP+ modules are capable of data rates up to 10Gbps over a distance of up to 10km. They are compliant with the SFP+ MSA specification and operate from 0~+70°C

Performance

Single-mode fiber (SMF) supported

Yes

SFP transceiver type

Fiber optic

Maximum data transfer rate

10000 Mbit/s

Interface type

SFP+

Multi-mode fiber (MMF) supported

Yes

Fiber optic connector

LC

Fiber cable diameters supported (core/cladding)

9/125 µm

Maximum transfer distance

220 m

Wavelength

1310 nm

Ethernet interface type

10 Gigabit Ethernet

Digital Diagnostics Monitoring (DDM)

Yes

Features

Plug and Play

Yes

Hot-Plug support

Yes

Hot-swap

Yes

Easy to install

Yes

Product colour

Nickel

Country of origin

United Kingdom

Certification

CE IEC60825-1

Certificates

Compliance certificates

RoHS

Operational conditions

Operating relative humidity (H-H)

0 - 95%

Operating temperature (T-T)

0 - 70 °C

Storage temperature (T-T)

-40 - 85 °C

Packaging content

Quantity per pack

1 pc(s)

Packaging data

Package type

Box

Package width

55 mm

Package depth

25 mm

Package height

120 mm

Package weight

35 g

Power

Input voltage

3.3 V

Weight & dimensions

Width

10 mm

Depth

15 mm

Height

60 mm

Weight

15 g

Technical details

Warranty period

1 year(s)

Logistics data

UK Trade Tariff code

85176200
