Universal Videobar Kit Av2-500wh - White

Introduction

The Neomounts AV2-500WH is a universal videobar kit for screens with a minimal size of 43? and VESA hole pattern ranging from 200x200 to 800x600 mm. The very sturdy, stable and versatile kit has a maximum weight capacity of 10 kg and can be installed either above or below the screen. For maximum adaptability, both the videobar support and the backplate brackets can be independently adjusted in height.

The AV2-500WH videobar kit is compatible with most videobars*, PTZ cams and soundbars, including Logitech Rally Plus speakers. To ensure a wide mounting applicability, the mounting holes can vary in width and height. The VESA frame can be adjusted both in height and width (200/400/600/800) and can be installed on wall, floor and even desk or ceiling mounts. Despite the numerous choices, installation is easy, aided by ruler-guided alignment for a seamless screen installation.
\t
* The Neomounts AV2-500WH videobar kit is universal and suitable for any type of videobar, regardless of make or model, within the range of the mounting bracket (see line drawing). In addition, the AV2-500WH is optimised for the following specific videobars:

- Bose Professional VB1 and VB-S
- Neat Bar and Bar Pro
- Poly Studio, Studio X70 and Studio X30
- Jabra Panacast 50
- Logitech Meetup, Rally Bar, Rally Bar Mini, Rally Bar Huddle and Rally Plus
- Cisco Webex Room Kit Plus
- Yealink MSpeaker II, MeetingBar A30, MeetingEye 400 and MeetingEye 600

Refer to the online manual for specific model or mounting size compatibility.

Features

Product type

Camera mount

Product colour

White

Placement supported

Wall/ceiling

Brand compatibility

Any brand

Compatible products

Bose Professional VB1 en VB-S Neat Bar en Bar Pro Poly Studio, Studio X70 en Studio X30 Jabra Panacast 50 Logitech Meetup, Rally Bar, Rally Bar Mini, Rally Bar Huddle en Rally Plus Cisco Webex Room Kit Plus Yealink MSpeaker II, MeetingBar A30, MeetingEye 400 en MeetingEye 600

Housing material

Steel, Acrylonitrile butadiene styrene (ABS)

Minimum VESA mount

200 x 200 mm

Maximum VESA mount

800 x 600 mm

Product type

Camera mount

Panel mounting interface

200 x 200,200 x 300,200 x 400,400 x 200,400 x 300,400 x 400,400 x 600,600 x 300,600 x 200,600 x 400,600 x 500,600 x 600,800 x 200,800 x 400,800 x 500,800 x 600

Minimum screen size

109.2 cm (43")

Maximum screen size

2.79 m (110")

Maximum weight capacity

10 kg

Product colour

White

Housing material

Steel

Minimum VESA mount

200 x 200 mm

Maximum VESA mount

800 x 600 mm

Minimum screen size

109.2 cm (43")

Maximum screen size

2.79 m (110")

Panel mounting interface

800 x 600 mm

Weight & dimensions

Width

900 mm

Depth

31 mm

Height

416 mm

Width

900 mm

Depth

31 mm

Height

416 mm

Weight

5.3 kg

Weight

5.3 kg

Maximum weight capacity

10 kg

Technical details

Total carbon footprint

20.05 kg of CO2e

Warranty period

5 year(s)

Total carbon footprint (kg of CO2e)

20.05

Warranty period

5 year(s)

Country of origin

China

Packaging data

Package width

220 mm

Package depth

84 mm

Package height

926 mm

Package weight

7.2 kg

Package weight

7.2 kg

Package width

220 mm

Package depth

84 mm

Package height

926 mm

Logistics data

Master (outer) case net weight

17.7 kg

Products per pallet (EU)

45 pc(s)

Master (outer) case width

263 mm

Master (outer) case length

238 mm

Master (outer) case height

944 mm

Master (outer) case gross weight

18.4 kg

Products per master (outer) case

3 pc(s)

Harmonized System (HS) code

7326909890

Country of origin

China

Products per master (outer) case

3 pc(s)

Master (outer) case gross weight

18.4 kg

Master (outer) case length

238 mm

Master (outer) case width

263 mm

Master (outer) case height

944 mm

Master (outer) case net weight

17.7 kg

Harmonized System (HS) code

7326909890

Products per pallet (EU)

45 pc(s)
