Core i5 Processor I5-14400t 1.5 GHz 20MB Smart Cache Tray

Processor

Processor manufacturer

Intel

Processor generation

Intel Core i5-14xxx

Processor model

i5-14400T

Processor family

Intel® Core™ i5

Processor cores

10

Processor socket

LGA 1700

Processor threads

16

Processor operating modes

64-bit

Performance cores

6

Efficient cores

4

Processor boost frequency

4.5 GHz

Performance-core boost frequency

4.5 GHz

Performance-core base frequency

1.5 GHz

Efficient-core boost frequency

3.2 GHz

Efficient-core base frequency

1.1 GHz

Processor cache

20 MB

Processor cache type

Smart Cache

Box

No

Processor base power

35 W

Maximum turbo power

82 W

Stepping

C0

Maximum number of DMI lanes

8

Memory bandwidth supported by processor (max)

76.8 GB/s

Processor codename

Raptor Lake

Processor ARK ID

236790

Memory

Maximum internal memory supported by processor

192 GB

Memory types supported by processor

DDR4-SDRAM, DDR5-SDRAM

Memory channels

Dual-channel

Memory bandwidth (max)

76.8 GB/s

Graphics

On-board graphics card

Yes

Discrete graphics card

No

On-board graphics card model

Intel UHD Graphics 730

On-board graphics card outputs supported

Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1

On-board graphics card dynamic frequency (max)

1550 MHz

Number of displays supported (on-board graphics)

4

On-board graphics card DirectX version

12.0

On-board graphics card OpenGL version

4.5

On-board graphics card maximum resolution (DisplayPort)

7680 x 4320 pixels

On-board graphics card maximum resolution (eDP - Integrated Flat Panel)

5120 x 3200 pixels

On-board graphics card maximum resolution (HDMI)

4096 x 2160 pixels

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

120 Hz

On-board graphics card refresh rate at maximum resolution (HDMI)

60 Hz

On-board graphics card ID

0x4682

Discrete graphics card model

Not available

Number of execution units

24

Multi-Format Codec Engines

1

Features

Execute Disable Bit

Yes

Idle States

Yes

Thermal Monitoring Technologies

Yes

Market segment

Desktop

Use conditions

PC/Client/Tablet

Maximum number of PCI Express lanes

20

PCI Express slots version

4.0, 5.0

PCI Express configurations

1x16+1x4, 2x8+1x4

Supported instruction sets

AVX 2.0, SSE4.1, SSE4.2

Scalability

1S

CPU configuration (max)

1

Embedded options available

Yes

Direct Media Interface (DMI) Revision

4.0

Export Control Classification Number (ECCN)

5A992C

Commodity Classification Automated Tracking System (CCATS)

740.17B1

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology)

Yes

Intel® Turbo Boost Technology

2.0

Intel® Quick Sync Video Technology

Yes

Intel® Clear Video HD Technology (Intel® CVT HD)

Yes

Intel® AES New Instructions (Intel® AES-NI)

Yes

Enhanced Intel SpeedStep Technology

Yes

Intel® Speed Shift Technology

Yes

Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0

Yes

Intel® Control-flow Enforcement Technology (CET)

Yes

Intel® Thread Director

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel® Secure Key

Yes

Intel® OS Guard

Yes

Intel 64

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel® Boot Guard

Yes

Intel® Deep Learning Boost (Intel® DL Boost)

Yes

Intel® Volume Management Device (VMD)

Yes

Mode-based Execute Control (MBE)

Yes

Intel® Standard Manageability (ISM)

Yes

Operational conditions

Tjunction

100 °C

Technical details

OpenCL version

3.0

Launch date

Q1'24

Status

Launched

Logistics data

Harmonized System (HS) code

8542310001

Weight & dimensions

Processor package size

45 x 37.5 mm

Other features

L2 cache

9728 KB

Maximum internal memory

192 GB

Graphics output

eDP 1.4b, DP 1.4a, HDMI 2.1
