Xeon Processor E-2324g 3.10GHz 8MB Cache

Introduction

Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple "virtual" platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Intel® Clear Video HD Technology
Intel® Clear Video HD Technology, like its predecessor, Intel® Clear Video Technology, is a suite of image decode and processing technologies built into the integrated processor graphics that improve video playback, delivering cleaner, sharper images, more natural, accurate, and vivid colors, and a clear and stable video picture. Intel® Clear Video HD Technology adds video quality enhancements for richer color and more realistic skin tones.

Cache
CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.

Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel® InTruT 3D Technology
Intel® InTruT 3D Technology provides stereoscopic 3-D Blu-ray* playback in full 1080p resolution over HDMI* 1.4 and premium audio.

Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don't.

Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Instruction Set
An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel's instruction set this processor is compatible with.

Intel® Quick Sync Video
Intel® Quick Sync Video delivers fast conversion of video for portable media players, online sharing, and video editing and authoring.

Intel vPro® Platform Eligibility
The Intel vPro® platform is a set of hardware and technologies used to build business computing endpoints with premium performance, built-in security, modern manageability and platform stability.


Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Intel® Clear Video Technology
Intel® Clear Video Technology is a suite of image decode and processing technologies built into the integrated processor graphics that improve video playback, delivering cleaner, sharper images, more natural, accurate, and vivid colors, and a clear and stable video picture.

Secure Key
Intel® Secure Key consists of a digital random number generator that creates truly random numbers to strengthen encryption algorithms.

Intel® Turbo Boost Technology 2.0 Frequency
Intel® Turbo Boost Technology 2.0 Frequency is the maximum single core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

Intel® Software Guard Extensions (Intel® SGX)
Intel® Software Guard Extensions (Intel® SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications' sensitive routines and data. Intel® SGX provides developers a way to partition their code and data into CPU hardened trusted execution environments (TEE's).

Instruction Set Extensions
Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.

Intel® OptaneT Persistent Memory Supported
Intel® OptaneT persistent memory is a revolutionary tier of non-volatile memory that sits between memory and storage to provide large, affordable memory capacity that is comparable to DRAM performance.  Delivering large system-level memory capacity when combined with traditional DRAM, Intel Optane persistent memory is helping transform critical memory constrained workloads - from cloud, databases, in-memory analytics, virtualization, and content delivery networks.

Intel® Memory Protection Extensions (Intel® MPX)
Intel® Memory Protection Extensions (Intel® MPX) provides a set of hardware features that can be used by software in conjunction with compiler changes to check that memory references intended at compile time do not become unsafe at runtime due to buffer overflow or underflow.

Intel® Boot Guard
Intel® Device Protection Technology with Boot Guard helps protect the system's pre-OS environment from viruses and malicious software attacks.

Intel® Transactional Synchronization Extensions
Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software.

Processor

Processor manufacturer

Intel

Processor model

E-2324G

Processor base frequency

3.1 GHz

Processor family

Intel Xeon E

Processor cores

4

Processor socket

LGA 1200 (Socket H5)

Component for

Server/workstation

Processor lithography

14 nm

Processor threads

4

System bus rate

8 GT/s

Processor operating modes

64-bit

Processor boost frequency

4.6 GHz

Processor cache

8 MB

Processor cache type

Smart Cache

Thermal Design Power (TDP)

65 W

Box

N

Cooler included

N

Memory

Maximum internal memory supported by processor

128 GB

Memory types supported by processor

DDR4-SDRAM

Memory channels

Dual-channel

ECC

Y

Graphics

On-board graphics card

Y

Discrete graphics card

N

On-board graphics card model

Intel UHD Graphics P750

Maximum on-board graphics card memory

64 GB

On-board graphics card base frequency

350 MHz

On-board graphics card dynamic frequency (max)

1300 MHz

Number of displays supported (on-board graphics)

1

On-board graphics card 4K support

Y

On-board graphics card DirectX version

12.1

On-board graphics card OpenGL version

4.5

On-board graphics card maximum resolution (DisplayPort)

5120 x 3200 pixels

On-board graphics card maximum resolution (eDP - Integrated Flat Panel)

5120 x 3200 pixels

On-board graphics card maximum resolution (HDMI)

4096 x 2160 pixels

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

60 Hz

On-board graphics card refresh rate at maximum resolution (HDMI)

60 Hz

On-board graphics card ID

0x4C9A

Discrete graphics card model

Not available

Number of execution units

32

Features

Execute Disable Bit

Y

Idle States

Y

Thermal Monitoring Technologies

Y

Market segment

Server

Use conditions

Server/Enterprise

Maximum number of PCI Express lanes

20

PCI Express slots version

4.0

PCI Express configurations

1x16+1x4,2x8+1x4,1x8+3x4

Supported instruction sets

SSE4.1,SSE4.2,AVX 2.0,AVX-512

Scalability

1S

CPU configuration (max)

1

Embedded options available

Y

Harmonized System (HS) code

8542310001

Export Control Classification Number (ECCN)

5A992CN3

Commodity Classification Automated Tracking System (CCATS)

G167599

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology)

N

Intel® Turbo Boost Technology

2.0

Intel® Quick Sync Video Technology

Y

Intel® InTru™ 3D Technology

Y

Intel® Clear Video HD Technology (Intel® CVT HD)

Y

Intel® AES New Instructions (Intel® AES-NI)

Y

Enhanced Intel SpeedStep Technology

Y

Intel Trusted Execution Technology

Y

Intel® Memory Protection Extensions (Intel® MPX)

Y

Intel® Turbo Boost Technology 2.0 frequency

4.6 GHz

Intel® Transactional Synchronization Extensions

N

Maximum Enclave Size Support for Intel® SGX

0.5 GB

Intel VT-x with Extended Page Tables (EPT)

Y

Intel® Secure Key

Y

Intel® OS Guard

Y

Intel Clear Video Technology

Y

Intel Software Guard Extensions (Intel SGX)

Y

Intel 64

Y

Intel Virtualization Technology (VT-x)

Y

Intel Virtualization Technology for Directed I/O (VT-d)

Y

Intel® Boot Guard

Y

Intel® Optane™ DC Persistent Memory Supported

N

Intel® vPro™ Platform Eligibility

Y

Operational conditions

Tjunction

100 °C

Technical details

Launch date

Q3'21

Status

Launched

Supported memory types

DDR4-SDRAM

Packaging data

Package type

Retail box

Weight & dimensions

Processor package size

37.5 x 37.5 mm

Other features

Maximum internal memory

128 GB
