Desktop USB-C Monitor - Series 5 Pro 524pu - 24in - 1920x1080 (FHD)

Introduction

Powerfully designed to connect
Plug into more possibilities with the HP Series 5 Pro 23.8” FHD USB-C? Monitor. Its sleek, modern design gives you crisp, stunning visuals and enhanced 100W power delivery with a single cable connection that seamlessly connects to PCs and peripherals at home or in the office.

Display

Display brightness

350 cd/m²

Display resolution

1920 x 1080 pixels

Touchscreen

No

Aspect ratio

16:9

Colour gamut standard

sRGB

sRGB coverage (typical)

100%

Response time measurement type

GTG (Gray to Gray)

LED backlight

Yes

Backlight type

Edge LED

Display diagonal

60.5 cm (23.8")

Display resolution

1920 x 1080 pixels

HD type

Full HD

Native aspect ratio

16:9

Display technology

LCD

Panel type

IPS

Touchscreen

No

Display brightness (typical)

350 cd/m²

Response time

5 ms

Display surface

Matt

Anti-glare screen

Yes

Screen shape

Flat

Supported graphics resolutions

1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA)

Aspect ratio

16:9

Contrast ratio (typical)

1500:1

Contrast ratio (dynamic)

10000000:1

Maximum refresh rate

100 Hz

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Display number of colours

16.7 million colours

Pixel pitch

0.28 x 0.28 mm

Pixel density

93 ppi

Horizontal scan range

30 - 115 kHz

Vertical scan range

50 - 100 Hz

Viewable size, horizontal

52.7 cm

Viewable size, vertical

29.6 cm

Display diagonal (metric)

60.5 cm

Haze rate

25%

Surface hardness

3H

Colour depth

8 bit

Colour gamut standard

sRGB

Colour gamut

100%

sRGB coverage (typical)

100%

Display bezel technology

Micro-Edge

Performance

Fast charging

Yes

NVIDIA G-SYNC

No

AMD FreeSync

No

Fast charging

Yes

Low Blue Light technology

Yes

NVIDIA G-SYNC

No

AMD FreeSync

No

Flicker-free technology

Yes

Low Blue Light technology

Yes

HP segment

Business

Operational conditions

Non-operating relative humidity (non-condensing)

20 - 80%

Operating relative humidity (H-H)

5 - 95%

Storage relative humidity (H-H)

20 - 80%

Operating temperature (T-T)

5 - 35 °C

Operating relative humidity (H-H)

5 - 95%

Storage relative humidity (H-H)

20 - 80%

Design

Feet colour

Silver, Black

Colour name

Jet black

Market positioning

Office

Product colour

Black, Silver

Detachable stand

Yes

Sustainability

Sustainability compliance

Yes

Sustainable technologies and materials

Low halogen; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; Outside box and corrugated cushions are 100% sustainably sourced and recyclable; 85% ITE-derived closed loop plastic; Contains ocean-bound plastic; Contains 20% recycled glass in the monitor panel; At least 40% recycled metal including 90% recycled aluminum in the stand

Sustainability certificates

ENERGY STAR

Network

Ethernet LAN

Yes

Remotely operated

Yes

Remotely operated

Yes

Multimedia

Built-in speaker(s)

No

Built-in speaker(s)

No

Built-in camera

No

Ports & interfaces

HDMI

Yes

Headphone out

No

USB Type-A downstream ports quantity

3

USB Type-C downstream ports quantity

1

USB Power Delivery up to

100 W

Built-in USB hub

Yes

USB hub version

3.2 Gen 1 (3.1 Gen 1)

USB Type-C DisplayPort Alternate Mode

Yes

USB Power Delivery (USB PD)

Yes

HDMI

Yes

HDMI ports quantity

1

HDMI version

2.0

DisplayPorts quantity

1

DisplayPort version

1.4

Headphone out

No

HDCP

Yes

Ergonomics

Cable lock slot

Yes

Swivel angle range

-45 - 45°

VESA mounting

Yes

Panel mounting interface

100 x 100 mm

Cable lock slot

Yes

Height adjustment

Yes

Adjustable height (max)

15 cm

Pivot

Yes

Swivelling

Yes

Tilt adjustment

Yes

Tilt angle range

-5 - 23°

On Screen Display (OSD)

Yes

Power

Energy efficiency class (HDR)

D

Power consumption (typical)

22 W

Power consumption (standby)

0.5 W

Power consumption (max)

198 W

Power consumption (off)

0.3 W

Energy efficiency scale

A to G

Power consumption (off)

0.3 W

Energy efficiency scale

A to G

Energy efficiency class (SDR)

Not available

Energy efficiency class (HDR)

D

Energy consumption (SDR) per 1000 hours

14 kWh

Power consumption (typical)

22 W

Power consumption (standby)

0.5 W

Power consumption (max)

198 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Power supply type

Internal

Carbon footprint

Total carbon footprint (kg of CO2e)

190

Carbon emissions, manufacturing (kg of CO2e)

153

Carbon emissions, logistics (kg of CO2e)

3

Carbon emissions, end-of-life (kg of CO2e)

2

Total carbon emissions, w/o use phase (kg of CO2e)

34

Other features

Weight

5.93 kg

Certification

Australian-New Zealand MEPS; BIS; BSMI; CB; CCC; CE; CECP; CEL Grade 1; cTUVus; EAC; FCC; ICES; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; VCCI; Vietnam MEPS; WEEE; ISC; California Energy Commission (CEC); UAE; TGM; Ukraine certificates; TÜV Flicker free certified; NRCS; PSE; GS; Ukraine EE; TÜV Low Blue Light Hardware Solution certified; Korea MEPS; Australian-New Zealand DoC; EMF

Manufacturer warranty

HP three-year limited warranty

Low halogen

Yes

Country of origin

China

UNSPSC-code

43211902

Weight

5.93 kg

Compliance certificates

BIS, BSMI, CB, CCC, CE, CECP, EAC, Federal Communications Commission (FCC), ICES, KC, KCC, Norma Oficial Mexicana (NOM), PSE, RCM, VCCI, WEEE, cTUVus

Ethernet LAN (RJ-45) ports

1

Certification

Australian-New Zealand MEPS; BIS; BSMI; CB; CCC; CE; CECP; CEL Grade 1; cTUVus; EAC; FCC; ICES; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; VCCI; Vietnam MEPS; WEEE; ISC; California Energy Commission (CEC); UAE; Ukraine certificates; TÜV Flicker free certified; NRCS; PSE; GS; Ukraine EE; TÜV Low Blue Light Hardware Solution certified; Korea MEPS; Australian-New Zealand DoC; EMF

Packaging data

Warranty card

Yes

Package width

621 mm

Package depth

140 mm

Package height

393 mm

Package weight

8.42 kg

Package type

Box

Technical details

Box contents

Monitor; Warranty card; AC power cable; Quick Setup Poster; 1 USB Type-C to Type-C cable

General Product Safety Regulation (GPSR) URL

https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true

Weight & dimensions

Width (with stand)

539.4 mm

Depth (with stand)

189.5 mm

Height (with stand)

503.2 mm

Weight (with stand)

5.93 kg

Width (without stand)

539.4 mm

Depth (without stand)

47.2 mm

Height (without stand)

314.3 mm

Packaging content

Cables included

AC

Quick start guide

Yes

Bundled software

HP Display Center; HP Client Management Script Library

Brand-specific features

HP GTIN (EAN/UPC)

197961408201
